NE-M01 Mesh Nebulizer – Portable Ultrasonic Inhalation therapy device.

The device forms nebulizing effect by the following actions, the high-frequency vibration of piezoelectric ceramic piece leads to the deformation of micro plate, so that the liquid in contact with the micro plate is atomized. It is powered by a 5 V power adapter or two AA alkaline batteries, with the advantages of compact and portable design, easy to use and high in nebulization rate, which is applicable for use in hospital, clinic and family.

Features: -

1. Simple and user-friendly design suitable for adults and children
2. High-frequency vibration ensures consistent and fine particle size for better absorption.
3. High nebulization rate for faster treatment sessions.
4. Produces uniform aerosol particles for deep lung penetration
5. Quiet performance suitable for use during sleep or for pediatric patients.

6. Compact structure ideal for travel and home use.
7. LED indicator shows device working status.
8. Alerts user when battery power is insufficient.

Technical Specification: -

• Median particle diameter: 3.7 μm
• Equivalent volume particle diameter distribution: the proportion of particle diameter below 5 μm is not less than 60 %
• Input power: < 15 VA
• Nebulization rate: ≥ 0.25 mL/min
• Cup capacity: 10 mL
• Liquid volume: 2 ~ 10 mL
• Working frequency: 110 KHz ± 10 %
• Power supply: DC 5 V or two AA alkaline batteries
• Safety class: class Ⅱ equipment, type BF applied part
• The degree of waterproof and dustproof: IP22
• Mode of operation: continuous operation
• Temperature: 5 ℃～40 ℃
• Humidity: ≤ 80 %
• Atmospheric pressure: 700 hPa～l060 hPa
• Dimension: 67 mm × 49 mm × 117 mm
• Weight: about 0.1 kg (excluding battery)
